LED Soccer Field Lights - Indoor Soccer Lighting

Request Price QuoteGet a free photometric report

LED Lights for Soccer Fields

Shop for LED Soccer Field Lights. Reduce overhead, improve light quality and reduce operating costs. Free photometrics available to reduce the risk of buying LED.

Soccer fields need to keep a pleasant experience to maintain visitors and fans, as well as great live broadcasting and recordings. With LED, a better experience is achieved along with great energy savings.

Why choose a MyLEDLightingGuide Soccer Field Lights?

1. High Voltage Solutions

100V-277V
277V-480V



We offer both standard voltage options of 100V-277V and high voltage options of 277V-480V. This include Canadian High Voltage standard of 347V.

Our soccer field lights also come with 10kVA and 20kVA surge suppression options. This keeps them safe in unsafe weather conditions.

2. High Power Solutions

Replace 1000W HID
Replace 1500W HID
Replace 2000W HID

Our LED Soccer Field Lights produce from 33,000 lumens to 133,000 lumens. A combination of high lumens - high power LEDs and optics can brighten any sports field with energy saving LED.

We can produce a free photometric evaluation of your outdoor space to show you how well our LED Soccer Field Lights work. It will show you what model is appropriate and what optic provides the best results for you outdoor space.

3. High Luminous Efficacy (Lumens Per Watt)

135 lm/w
160 lm/w

Luminous efficacy is the major indicator of the performance of a LED bulb. It is calculated as the lumens generated for a single watt of electricity pulled. Luminous efficacy measures how well a bulb produces visible light. Which is usually measured in lumens.

We offer LED Soccer Field Lights with excellent efficacy ratings. This will save you even more money over early generation LED Lights.

4. The Right Beam Angle

15°
30°
60°
90°
120°

The beam angle usually dictates the distribution of light. If the beam angle is wide and the light uniformity is very high, the brightness on the ground will be very low. But, if the beam angle is narrow, the light uniformity is low. Many dark spots are on the ground despite the brightness of the light.

Choose lights that have the right beam angle balancing light uniformity with brightness. Our lighting engineers can show you by doing a photometric analysis. This will help you choose lights with the right beam angles.

How can you tell what optic is the best?

You can't. And that's the problem when you buy off the shelf led products from large ecommerce vendors. Many times the beam angle is not listed. And even if it was, how do you know its the proper light / optic / lumen package? You don't. Check out our photometrics section below. We will provide you with a free photometric report giving you options and taking all the risk out of purchasing LED.



5. Excellent Heat Dissipation






Heat sinks prevent LED lights from getting damaged because of overheating. Good ones are usually made of pure aluminum which has the best heat conducting rate (238W/mk). The higher the value of the aluminum, the higher its conductivity rate. A good heat dissipation system should provide enough air ventilation passage.

There should be space between each single row of LED chips. The structure should be hollow to reduce air resistance. This helps transfer heat from the lamp to the surrounding area. The heat dissipation section should also be large and dense. Aluminum fins can quicken the cooling process.

6. High CRI

70 CRI
80 CRI



The color rendering index shows how well colors are seen under a certain light source. It defines how a bulb makes an object appear to human eyes. The higher the color rendering index, the better a bulb’s color rendering ability.

When it comes to soccer and sports lighting, the color rendering index needs to be 70 and above. We can offer 70 and 80 CRI sport lighting solutions.

7. Glare Rating



While the glare rate is seldom mentioned, it is very essential in sports lighting. Too much glare may lead to visual discomfort and cause people to squint as they watch or play a game. It may also impair the vision of details and objects. For example, players may be unable to see fast-moving balls. Glare also reduces the brightness of the light in some areas.

Our led lights have advanced lenses that focus the light beam and decrease light leakage by 50%.

LED Soccer Field Light Choice

The glare rating for all light fixtures used in top level competitions must be 50. Fixtures used in intermediate level competitions must also have a glare rating of 50, except those used in athletics which should have a rating of 55. For lower level competitions, the lights must have a glare rating of 55, except those used in bowls (lawn bowls) which should have a glare rating of 50.

8. Color Temperature

4000K
5000K

Organizations specify the minimum allowable color temperature (correlated color temperature) for sports fields. For instance, FIFA and FIH require their lights to have a CCT of 4000K and above.

Our eyes adapt well to light sources with different color temperatures. Television and digital cameras do not. They must be adjusted to display the colors humans expect to see. This is why it is so important for LED lights in a sports venue to have the proper correlated color temperature. If they don’t, TV cameras will display irritating color shifts as they move across the field.

We offer 4000K and 5000K LED Sport and Soccer Lighting solutions.



9. Energy savings up to 80%

50-80%

savings

If we were to use sports terms to describe the energy-efficiency of LEDs, we would say that they are a slam dunk. This is because they generate more light while consuming less electricity. LED sports and soccer field lights have gotten popular in a very short time. The major reason why is because of the savings they offer teams, clubs, and owners of sports venues.

Metal halides have a life expectancy of 12,000 - 20,000 hours while LEDs have a rated life of 50,000 - 100,000 hours. Since LEDs last much longer than metal halide lamps, they are perfect for use in stadiums. They are also very well-built and need very little maintenance during their lifetimes.

LED lights can reduce energy consumption by as much as 90%. Pairing them with lighting controls ensure stadium lights are on only when needed. And if the lights are not used every day of the week, their life expectancy goes up.

10. Wet Location - Must be Waterproof

IP65
IP66

The longevity and efficiency of light fixtures depends on where you install them. Stadium lights are outdoors and affected by conditions such as water and humidity. This is why they must be designed for wet locations.

Wet locations where water can flow, drip, or splash on the fixtures can affect the components. The light fixtures must be UL Listed for wet locations. They should have an IP rating of 66. IP66 rated lights work well in all weather conditions for soccer and sports fields.

Photometrics with LED Soccer Field Lights

Why are photometrics important? They allow you to see your area and how it would look under LED Lighting taking the risk out of buying. We can easily run different options with our lights, and provide you with the proper information and guidance. We're here to save you money with LED. But it's as important to get the lighting right.

Mini Soccer Field Lighting - 4 poles, 2 lights per pole

FIFA Sanctioned Soccer Field - (164) 1200W LED Stadium Lights - 170 fc average
